    Na 40135 Large capacity cylindrical cell

    Rated capacity

    15Ah

    Rated voltage

    3V

    Internal resistance

    ≤2mΩ

    Dimension

    φ40*135mm

    Energy density

    ≥137Wh/kg

    Weight

    375±15g

    Standard Charge Current

    0.5C

    Standard Discharge Current

    0.5C

    Storage Temperature

    -20℃~45℃

    Discharge Temperature

    -40℃~60℃

    Charge Temperature

    0℃~60℃

    Low temperature discharge capacity retention rate

    -40℃:≥80%

    Rate capability

    Continuous Discharge Rate 2C,Pulse Discharge Rate 5C(10S)

    Application Market
    • EV 2&3 wheelers

    • Home Energy Storage

    • Communication energy storage

    • Logistics vehicles

    • Outdoor energy storage

    • Passenger cars

    Product advantages


    1、Ultra-fast charging: 10 minutes of ultra-fast charging;

    2、Excellent rate performance: 5C continuous rate discharge , pulse discharge rate of

    more than 10c;

    3、Excellent rate cycle performance: outstanding long cycle performance, 2C charge and

    5C discharge, rate cycle reaches more than 5000 times;

    4、Excellent low-temperature performance: Battery discharge capacity reaches more

    than 80% at .40'C, suitable for use in cold areas, can work normally at -40°C .60°C

    5、Large capacity: High capacity for single cell,reduce the cost of assembly, easy to control

    by BMS; resistant to over-discharge, the battery can be discharged to 0v without

    affecting subsequent use;

    6、Small lR & low temperature rise: All-tab end welding technology greatly reduces lR,

    charge & discharge temperature rise, reduces module temperature, and increases cycle

    life by 20%;

    7、Safety performance: Chemically stable sodium electric material system, cap with

    explosion-proof valve device, sealing technology of shell laser welding;

    8、Good consistency: Highly automated production lines and multi-parameter dynamic

    characteristic matching technology.
